Customlines for Google Maps Polylines

google-maps polyline

TL;DR The Github Example: https://github.com/TheCell/devSpace/tree/master/googleMapsExample and the Website in Action: http://dev.thecell.eu/mapsWithPolylines/

Create Map

The Google Map needs a Container Div and respects a couple of parameters. You’ll need a maps API Key, thats not covered here. Take a look at https://developers.google.com/maps/documentation/javascript/get-api-key

[code language=“javaScript”]

#map { width: 100vw; height: 100vh; } </style> </head> <body> <div id="map"> </div> <script src="https://maps.googleapis.com/maps/api/js?key=AIzaSyBXxxzlonPc1QcpgD47wnRGC6pJSGIfEek"></script>

\[/code\] Some Common Options are zoom, center, styles, disableDefaultUI, and even a cursor image encoded in base 64:


Cursor

The Cursor takes a Base64 string representing an image like the code above. You can get base64 codes by having a canvas, draw an image on it and then use javascript to get the base64 encode like this:

[code language=“javaScript”]

\[/code\]

Or use a Website like https://www.base64-image.de/ that does basically the same for you. The draggableCursor needs the base64 surounded by url('..') and , auto. If the auto is not there it won’t render.

Map Style

The Map can be styled to any extend imaginable. Visit https://mapstyle.withgoogle.com/ to set your style and after that you can get a url or just copy the json and add it to the options: [code language=“javaScript”] // this is an extremely incomplete example! let mapStyleJson = [ { “elementType”: “geometry”, “stylers”: [ { “color”: “#ebe3cd” } ] } ]; [/code] Just add the mapStyleJson to the options list under styles

Polyline

Polylines have a wide variety of options, take a look at the (underwhelming) documentation: https://developers.google.com/maps/documentation/javascript/examples/polyline-complex. I will only cover the drawing on the Line part here. It is possible to add SVG’s on to the Lines. It accepts an array of icon objects:

[code language=“javaScript”] // add custom Line Drawings // https://developers.google.com/maps/documentation/javascript/reference?#IconSequence let iconsequ = []; // SymbolPath https://developers.google.com/maps/documentation/javascript/reference?#SymbolPath let circle = { “path”: “M -2,0 C -1.947018,-2.2209709 1.9520943,-2.1262691 2,0.00422057 2.0378955,1.3546185 1.5682108,2.0631345 1.4372396e-8,2.0560929 -1.7155482,2.0446854 -1.9145886,1.0142836 -2,0.06735507 Z”, “fillColor”: “#ff0024”, “fillOpacity”: 0.8, “strokeColor”: “#ff0024”, “strokeWeight”: 20, “scale”: 1 };

// add Point at the start of the Line iconsequ.push( { icon: circle, offset: “0%”, repeat: “0” });

// add Point at the end of the Line iconsequ.push( { icon: circle, offset: “100%”, repeat: “0” });

// create polyline between points, add start and end point // https://developers.google.com/maps/documentation/javascript/symbols let poly = new google.maps.Polyline( { path: [{“lat”: 46.101707, “lng”: 7.715639}, {“lat”: 46.125801, “lng”: 7.745851}], strokeColor: “#f45f42”, strokeOpacity: 1.0, strokeWeight: 1, icons: iconsequ });

poly.setMap(map); [/code]

repeat: 0 = turn repeat off. 25% = show the symbol every 25% of the Line. 25px = show the symbol every 25px Note: The % will make sure that the symbol is visible a fixed amount of time (if there is enough space on the line).

SVG Paths

For the SVG Paths take a look at the w3schools Path examples: https://www.w3schools.com/graphics/svg_path.asp or for more technical information consider https://developer.mozilla.org/en-US/docs/Web/SVG/Tutorial/Paths. You can use Inkscape aswell (https://inkscape.org/de/). Open it up and enable the XML viewer (Edit > XML-Editor). On the Right you can inspect the svg paths drawn.

However it is important to note, that you can only use the paths d= value. This means you’ll have to consider the list of possible commands:

M = moveto L = lineto H = horizontal lineto V = vertical lineto C = curveto S = smooth curveto Q = quadratic Bézier curve T = smooth quadratic Bézier curveto A = elliptical Arc Z = closepath
